Primary Use: Commercial
Power Type: Battery
The battery-powered KMA 135 R KombiMotor delivers truly professional performance on par with gas-powered products with reduced noise and zero exhaust emissions. With over a dozen optional attachments, the KMA 135R provides users the ability to tackle a range of landscaping jobs without loading the trailer with a pile of tools.
NOTE: STIHL KombiMotor and STIHL KombiSystem attachments are sold separately.
Adjustable front handle
The front handle is easily adjustable (360-degree rotation) for comfort.
Reduced-Emission Engine Technology - Caring for Nature
The STIHL Inc. “Caring for Nature” seal identifies its powered products that are more environmentally conscious, producing zero or low exhaust emissions. STIHL Inc. defines “low exhaust emissions” as being cleaner than EPA and/or CARB exhaust emission standards.
Throttle Trigger Interlock
Must be depressed before the trigger can be activated.
STIHL Electric Motor
Lightweight and compact, STIHL electric motors require minimal maintenance and feature low noise levels and reduced vibration.
Safety Locking Button
All STIHL Battery powered products feature a retaining latch that is designed to prevent the unit from unintentional starts when the battery is inserted.
See it in action!
To transfer power, the socket and the tool is connected to the STIHL AP or AR batteries using the connecting cable. This means that the battery can be conveniently worn on the body.
Loop Handle (R)
The loop handle (R) is an adjustable rounded handle mounted on a shaft for support and control. The handle is designed to help control the machine in different positions, ideal for reaching tough spots. The handle is large enough to accommodate a gloved hand comfortably.
Multi-Function Control Handle
Having easy access to all of the controls on one comfortable handle help makes it easier to complete tasks so the operator’s hand never has to leave the handle.
The quick-release coupling system makes it easy to switch between Kombi attachments. In addition, this feature allows KombiSystem equipment to be dismantled into two parts for easy transport and storage and then re-assembled quickly without tools.
|KMA 135 R Specifications|
|SPEED SETTINGS||Level 1: 6,200 RPM
Level 2: 7,700 RPM
Level 3: 8,500 RPM
|MAX SPEED||8,500 RPM|
|BLOWING FORCE WITH BG-KM||15 Newtons|
|AIR VELOCITY WITH BG-KM||150 mph|
|AIR VOLUME WITH BG-KM||480 cfm|
